Keyboard Connectors

A variety of keyboard connectors are in use in the world today.  Here are a couple:

• DIN-5 (IBM-PC)
• PS2 (Mini-DIN-6)



DIN-5 (IBM-PC)



Pin	Name/Description
1	Clock
2	Data
3	Not connected (Reset on some very old keyboards)
4	Ground
5	+5 VDC



---

PS2 (Mini-DIN-6)



Pin	Name/Description
1	DATA
2	N/C
3	GND
4	VCC (Power , +5 VDC)
5	CLK
6	N/C
